Description
20.5*25.5mm Square 24V Neon Flex LED Light Strip SMD 2835 with End Cap Connector Profile
Non-flammable, non-fading, never change to yellow – neon LED Flex are realiable, durable, very safety for indoor&outdoor decoration. Top quality, 2 or 3 years warranty.
Unlike glass neon lights that have to run on a very high voltage of 15, 000V, the square LED Flexible Neon Strip operates internally on 24V or 12V.
The LED Neon Flex Consumes only 8W per meter without light pot, adapt Integrated Molding Design, max can powered 20 meters by one-end power supply.
It can also be cut according to scissor mark through which enduser an custom made their ownlength easily.
LED Neon Flex is shatterproof, emits very little heal and is absolutely safe to use underwater.
LED Flexible Neon comprised of string of LED’s spaced at a specific distance apart sufficientilluminate the specially designed oval-shaped encapsulating jacket to produce light with uniformity and neon-like brightness.
Neon LED Flex not only support Long connect length, but also have Low voltage, low energy used and cuttable, easy to installation, can save your tremendous labor costs and energy cost.
The Square LED Neon Flex with different control method,
Remote control dimmer
2.4G RF control dimmer
Wifi Tuya Control dimmer
All in one Integrated dimmer Control system
If you’d like on of your own, talk to us!
|
Product Name
|
LED Flexible Neon Tube Light
|
|
Model No.
|
LM2835-120D-20.5MM-NEON TUBE
|
|
Size(mm)
|
20.5*25.5mm
|
|
Applicable LED Beads
|
2835 120leds/m
|
|
Voltage(V)
|
12V/24V DC
|
|
PCB Width
|
10MM
|
|
PCB Materials
|
2Oz Double-sided coated pure copper
|
|
Cut Unit
|
3LEDs 25mm/cut(12V), 6LEDs 50mm/cut(24V)
|
|
Rated Power(W)
|
8W/M
|
|
Color
|
W/WW/CW/R/G/B/Y/Pink
|
|
LED Chip Brand
|
Sanan, Samsug, Osram, Epistar optional
|
|
LED Supplier
|
Honglitronic/Osram/Samsung
|
|
LED’s Material
|
Packaged by 99.99% pure gold wire
|
|
LED Bins
|
3-Step/5-Step, same BIN for each order
|
|
CRI(RA>)
|
CRI80
|
|
Color Temperature
|
2200K,2700K,3000K,3500K,4000K,6000K,7000K
|
|
IP Rate
|
IP67
|
|
View Angle
|
120°
|
|
Package(m/roll)
|
50M/roll(1m/roll,5m/roll,10m/roll.20m/roll,100m/roll. Customized length available)
|
|
Certificate
|
CE,RoHs,FCC
|
|
Warranty
|
2 years or 3 Years
|
24v neon flex
flex neon smd 2835
NEW TYPE NEON LED LIGHT: Replacement for traditional Neon lighting of Structure outline such as Roofs, Windows, Doors, Storefronts and Carports. Perfect for home and garden lighting decoration.
EASY TO INSTALL: Waterproof Neon light strip can use Indoor and Outdoor, Plug and Play without wiring,12V/ 24V, 110-120V, 220V-240V Powered.
LOW POWER CONSUMPTION: Super Bright LED light running with Low Temperature. All the light spread and completely smooth, luminous very even.
FLEXIBLE AND CUTTABLE: Neon light strip can be shaped, formed or bent in any angle. It can be cut in every 3.28Inch/8.33cm without damaging the rest strips.
ECO-FRIENDLY: No splash and UV, without mercury and no damage to human and environment.
