Description
D40mm 360 Degree Addressable Neon Flex LED Tube Pixel 360 DMX Neon Bar 192leds/m
| Product Name | 360 Degree Addressable Neon LED Flex |
| Diameter | D25mm/D40MM |
| LED Type | SK6812 IC-5050 |
| Voltage | DC5V |
| LED Quantity | 192leds/m |
| Waterproof Rate | IP67 waterproof |
| Certificate | CE, RoHS |
| Warranty | 3Years |
| Power28w/m | |
| Application | 1.Shopping mall, restaurant, hotel, meeting room and advertisement lighting and decoration and so on.
2. Window display lighting 3.Architectural decorative lighting 4.Building decoration |
The 360 Degree Addressable Neon light are Flexible, it a kind of comfortable light which are no Blindness Point, the full tube Circle without any dark area.
360° viewing addressable led tube pixel in Diameter 40mm, 192pcs SK6812 IC LEDs per meter, 5 Volt, adapt high light transmittance, Environmentally Silicone material, can glows evenly without spotting.
Standard length is 1m/pcs, MAX can be 2.5 meters, the length and wires can be customize for different application request. You’d better cut your target length in our factory before deliver.
IP67 waterproof grade support outdoor use, Working Temperature -30~50℃, salt resistance, Acid and alkali Resistance, Corrosion Resistance, Flame Retardant Resistance, UV resistance. Each meter contains 2 clips for installation.
360 LED neon flex dmx
360 neon flex dmx
neon flex 360 dmx
neon plexi light 360
neon led rgb 360
neon led 360
360 degree neon
360 neon flex adressable
360 Neon Flex
led neon 360 lamp
Pay Attentions:
1. This is low voltage product, please use DC constant voltage isolated power supply to drive led strip.
2. In actual applications, the constant voltage power supply should retain a margin of 20% (only 80% of the power is recommended) to ensure sufficient voltage to drive the product.
3. Please pay attention whether the positive and negative poles of the power supply and the power cord are the same, and do not connect them incorrectly to avoid damage for the product.
4. Please avoid scratching, twisting and irregular bending of the product during the installation process, otherwise it may cause the waterproof level to drop and cause irreparable damage.
5. In order to ensure the lifetime and reliability of the strip, please do not bend it in an arc less than 240mm in diameter. too small bending radius will damage the product itself.
6. The use of exceeding standard cascade length will cause the strip to overload and heat, voltage drop and brightness not uniform.
7. To ensure safety use, please ask professional to install .
8. It is strictly forbidden to use any acidic or alkaline adhesives to fix products (including but not limited to glass glue, etc.)
9. IP65 not suitable for immersion environment .
10. Different sizes of products under the same color temperature, based on the difference in structure, the final color of the product is slightly different, please check the actual sample before use.
